Chemical Feed Pumps

Metering Pumps:​

• Membrane System Pre-Treatment

• Antiscalant

• Acid

• Caustic

• Sanitizing Chemicals

• Coagulants​

• Flow controlled
• Flow Feed Back

• Degassing Heads


Peristaltic Hose Pumps:​

SPX10 Pump

• ​Max flow: 2,385 ml/min [0.63 GPM]

• Capacity: 0.006 G/rev

• Max Discharge Pressure: 174 psi

• Max Temperature: 176 F

• Inner Diameter Pump Element: 10 mm

• Lubricant required: 0.07 G

• Starting torque: 416 inch-lbs

• Max Lime Slurry Viscosity: 30%

• 120 VAC plug for standard receptacle connection .

• Digital VFD controller


​​

SPX15 Pump

• ​Max flow: 8,782 ml/min [2.32 GPM]
• Capacity: 0.022 G/rev

• Max Discharge Pressure: 174 psi

• Max Temperature: 176 F

• Inner Diameter Pump Element: 15 mm

• Lubricant required: 0.1 G

• Starting torque: 531 inch-lbs

• Max Lime Slurry Viscosity: 30%

• 120 VAC plug for standard receptacle connection.

• Digital VFD controller


Available Parts:

• NSF approved Lubricant
• 10 mm & 15 mm Replacement Hoses
• Automatic Flush Assemblies

Lyons Filter Company offers a wide verity of Chemical Feed Pumps and Pump Systems.
